Web Page Configuration Of the Logger

The NDACS logger operations are fully configurable using the instruments in built web pages. The following instructions only detail what is required to configure the logger to record data and report automatically using the GSM modem. For any additional information regarding the logger operations see the NDACS manual.


Accessing the Logger Web Pages

to access the looger web pages enter the command

http:// Instrument IP-Address

Example. Logger with IP address 23.0.0.95

http://23.0.0.95 into the address bar of a web browser.

As long as the network of the analysis PC is suitably configured then the instrument web pages will now appear.

Tide Height from Level Sensor

Fig 14

Results Web Page

Date & Time

Cold Junction
Temperature
